    LXC-260S

    Lianxing Computerized flat knitting machines are used digital technology to achieve the patterns of transfer, tuck, pointel, intarsia, jacquard, apparent shape, hidden shape and other regular pattern knitting functions, can knit basic single or double jersey plain fabric, irregular multi-colors jacquard, intarsia, cable and pointel structure patterns.
    Knitting Area:Sweater,Scarf,Hat,Collar&Cuffs,Car seat,Shoes upper,Medical device,ballproof clothes,ect.

    Brand


    Gauge

    LIANXING


    2.5G,3G,3.5G,4G;

    Knitting width

    60" WEIGHT:ABOUT1280-1380KGM

    Knitting speed

    Controlled by AC servo motor with 24 sections

    speed optional, max 1.2m/s;

    Knitting system

    GE21:single carriage with double systems;

    Knitting function

    Knit, miss, tuck, transfer, pointelle, intarsia, jacquard,

    hide,or apparent shaping and other regular patterns.

    High-speed double

    tables technology

    The scope of racing reached 6 inches and raises

    the efficiency of table running by 40%,easy to deal

    with the pattern of twisting and fair isle;

    Dynamic stitch

    The skill is initiation in China and at the same level

    with similar machines internationally.Different

    tightness is allowed on the same line without

    problem of varying lengths while knitting.When

    group of rib,twisted flower and frong-back are

    knitted on the same line,they are allowed to

    loosen alone;

    Technology of stitch motor

    closed-loop control

    Intelligently controlling the working condition of

    stitch motor is phased with this technology,

    avoiding the problem of wrong tightness while

    knitting;

    Rapid gyration

    With rapid gyration in one-needle period,the

    efficiency can be raised by 14% especially when

    knitting narrow weaving like sleeve or stitching;

    Intelligent traction control

    Provide kinds of traction;slove the problem that

     traction may be lacking on thick-needle machine;

    release traction to make stitch transfer more stable;

    Picture alarm

    Alarm function with vivid images to make it easier;

    Function of intelligent

    computer file

    Create parameters like thickness,traction and speed

    with intelligent plate making program,save time for

    creating parameters on the machine;

    Control system

    1,Screen:adopt 10.4 inches LCD touch screen and

    figure interface;

    2,Adopt intelligent head box(CAN bus technology);

    Power

    Single-phase 220V/50HZ,1.5KW,adopt advanced CMOS technology

    enabling memorizing at the instant of power outages

    and restoring of knitting thereafter.
